Product Name : CK-500
Product Description

110V or 220V-240V×1ph AC

Product Introduction

Features:

Lightweight and compact design for easy installation

Dynamic and mechanical brake provides instant and safe braking

Operates on standard household power supply

Enclosed drum flanges to prevents ropes becoming trapped between drum and support castings

Specifications
Capacity(kg) 500
Lifting speed m/min First layer 7
Top layer 11
Motor KW × A Type Series wound
110V 1.4×13
220V-240V 14×6.5
Maximum lifting height m 29
Braking methods For motor Electromagnetic brake
For gear Mechanical brake
Wire rope Diameter mm 6.35
Length m 30
Construction 6×19
Drum dimension mm Width 115
Drum Dia 80
Flange Dia 123
Mounting bolt pattern mm 85×155
135×165
Net weight kg 28
Gross weight kg 30

Warning:

Winches are not to be used for the moving of persons.



Warranty:

Each new winch is guaranteed against defects in workmanship and material defects for a period of twelve months from date of purchase.

Wire ropes are not included under warranty.



Standard Accessories:

Wire rope 6.35mm × 30m

Switch cord 2mm² × 6C  × 6m

Power lead 2mm² ×  3C × 4.5m

Pendant switch K-613



Optin Accessories:

Remote control K-613A assembly
